| Business Type | Manufacturer, Exporter, Supplier |
| Table Size | 160 X 520 MM |
| Longitudinal Travel | 150 MM |
| Table Travel | 480 MM |
| Click to view more | |
Preferred Buyer From
| Location | Worldwide |
Product Details
Drilling Capacity
25 MM
Automatic Grade
Automatic
Condition
New
Spindle Speed
SIX SPEED
Speed Range
73 to 1850 RPM
Spindle Nose
MT-3
Spindle Center to Column
225 MM
Spindle Travel
150 MM
Maxi. Distance Spindle to Table
700 MM
Maxi.Distance Spindle to Base
940 MM
Working Surface of Base
300 X 320
Working Surface of Table
160 X 520
Column Diameter
74 MM
Machine Base
470 X 320
Motor
1 HP / 1440 RPM
V Belt Size
B-46
Weight of Machine (Approx.)
150 kg
Cross Travel (Left to Right )
300 MM
We have built a good reputation in the development and innovation in the field of machine tools as we provide world-class machines accurately and quickly to our customers. These drilling machines are assembled by our dedicated team of skilled craftsmen under the guidance of our experts. This machine can be used for a range of jobs from freely swivelling joints to clamped.
