| Business Type | Manufacturer, Exporter, Supplier |
| Width | 1080 Mm |
| Working Roll Length | 2100 mm |
| Bending Thickness (MS.) | 6 mm |
| Click to view more | |
Preferred Buyer From
| Location | Worldwide |
Product Details
Pre-Bending Thickness (SS.)
4 mm
Top Roll Diameter
160 mm
Bottom Roll Diameter
140 mm
Motor H.P.
3
Lenght
3950 mm
Height
1160 mm
Technical data
| Model product name 3 Roll Plate Bending Machine | Working Roll Length | Bending Thickness (MS.) | Pre-Bending Thickness (SS.) | Top Roll Diameter | Bottom Roll Diameter | Motor H.P. | Lenght | Height | Width |
| MPBD-3R-0621 | 2100 mm | 6 mm | 4 mm | 160 mm | 140 mm | 3 | 3950 mm | 1160 mm | 1080 mm |
| MPBD-3R-0821 | 2100 mm | 8 mm | 6 mm | 190 mm | 170 mm | 5 | 3950 mm | 1160 mm | 1080 mm |
| MPBD-3R-1021 | 2100 mm | 10 mm | 8 mm | 210 mm | 190 mm | 10 | 3950 mm | 1160 mm | 1080 mm |
| MPBD-3R-1221 | 2100 mm | 12 mm | 10 mm | 230 mm | 210 mm | 10 | 4030 mm | 1275 mm | 1370 mm |
| MPBD-3R-1621 | 2100 mm | 16 mm | 12 mm | 270 mm | 250 mm | 15 | 4180 mm | 1385 mm | 1440 mm |
| MPBD-3R-2021 | 2100 mm | 20 mm | 16 mm | 300 mm | 270 mm | 20 | 4440 mm | 1630 mm | 1620 mm |
| MPBD-3R-2521 | 2100 mm | 25 mm | 20 mm | 330 mm | 300 mm | 20 | 4250 mm | 1850 mm | 1800 mm |
| MPBD-3R-3021 | 2100 mm | 30 mm | 25 mm | 360 mm | 330 mm | 25 | 4500 mm | 2000 mm | 1900 mm |
| MPBD-3R-4021 | 2100 mm | 40 mm | 30 mm | 390 mm | 360 mm | 30 | 4900 mm | 2200 mm | 2000 mm |
| MPBD-3R-5021 | 2100 mm | 50 mm | 40 mm | 430 mm | 390 mm | 40 | 5200 mm | 2500 mm | 2200 mm |
| MPBD-3R-0626 | 2600 mm | 6 mm | 4 mm | 190 mm | 170 mm | 5 | 4450 mm | 1160 mm | 1080 mm |
| MPBD-3R-0826 | 2600 mm | 8 mm | 6 mm | 210 mm | 190 mm | 10 | 4450 mm | 1160 mm | 1080 mm |
| MPBD-3R-1026 | 2600 mm | 10 mm | 8 mm | 230 mm | 210 mm | 10 | 4530 mm | 1300 mm | 1370 mm |
| MPBD-3R-1226 | 2600 mm | 12 mm | 10 mm | 270 mm | 250 mm | 15 | 4680 mm | 1350 mm | 1450 mm |
| MPBD-3R-1626 | 2600 mm | 16 mm | 12 mm | 300 mm | 270 mm | 15 | 5000 mm | 1650 mm | 1650 mm |
| MPBD-3R-2026 | 2600 mm | 20 mm | 16 mm | 330 mm | 300 mm | 20 | 5000 mm | 1850 mm | 1850 mm |
| MPBD-3R-2526 | 2600 mm | 25 mm | 20 mm | 360 mm | 330 mm | 25 | 4900 mm | 1950 mm | 1850 mm |
| MPBD-3R-3026 | 2600 mm | 30 mm | 25 mm | 390 mm | 360 mm | 30 | 5400 mm | 2150 mm | 2000 mm |
| MPBD-3R-4026 | 2600 mm | 40 mm | 30 mm | 430 mm | 390 mm | 40 | 6000 mm | 2250 mm | 2200 mm |
| MPBD-3R-0631 | 3100 mm | 6 mm | 4 mm | 210 mm | 190 mm | 7.5 | 5000 mm | 1200 mm | 1100 mm |
| MPBD-3R-0831 | 3100 mm | 8 mm | 6 mm | 230 mm | 210 mm | 10 | 5100 mm | 1300 mm | 1400 mm |
| MPBD-3R-1031 | 3100 mm | 10 mm | 8 mm | 270 mm | 250 mm | 10 | 5200 mm | 1400 mm | 1500 mm |
| MPBD-3R-1231 | 3100 mm | 12 mm | 10 mm | 300 mm | 270 mm | 15 | 5500 mm | 1700 mm | 1700 mm |
| MPBD-3R-1631 | 3100 mm | 16 mm | 12 mm | 330 mm | 300 mm | 20 | 5700 mm | 1900 mm | 1900 mm |
| MPBD-3R-2031 | 3100 mm | 20 mm | 16 mm | 360 mm | 330 mm | 20 | 5700 mm | 1900 mm | 1900 mm |
| MPBD-3R-2531 | 3100 mm | 25 mm | 20 mm | 390 mm | 360 mm | 25 | 5900 mm | 2000 mm | 2100 mm |
| MPBD-3R-3031 | 3100 mm | 30 mm | 25 mm | 430 mm | 390 mm | 30 | 6000 mm | 2200 mm | 2300 mm |
| MPBD-3R-4031 | 3100 mm | 40 mm | 30 mm | 460 mm | 420 mm | 40 | 6200 mm | 2450 mm | 2400 mm |
| MPBD-3R-5031 | 3100 mm | 50 mm | 40 mm | 510 mm | 460 mm | 60 | 6400 mm | 2800 mm | 2500 mm |
| MPBD-3R-0641 | 4100 mm | 6 mm | 4 mm | 270 mm | 250 mm | 7.5 | 6200 mm | 1400 mm | 1500 mm |
| MPBD-3R-0841 | 4100 mm | 8 mm | 6 mm | 300 mm | 270 mm | 10 | 6200 mm | 1700 mm | 1700 mm |
| MPBD-3R-1041 | 4100 mm | 10 mm | 8 mm | 330 mm | 300 mm | 10 | 6400 mm | 1900 mm | 1900 mm |
| MPBD-3R-1241 | 4100 mm | 12 mm | 10 mm | 360 mm | 330 mm | 15 | 6500 mm | 1900 mm | 1900 mm |
| MPBD-3R-1641 | 4100 mm | 16 mm | 12 mm | 390 mm | 360 mm | 20 | 7000 mm | 2000 mm | 2000 mm |
| MPBD-3R-2041 | 4100 mm | 20 mm | 16 mm | 430 mm | 390 mm | 20 | 7200 mm | 2200 mm | 2200 mm |
| MPBD-3R-2541 | 4100 mm | 25 mm | 20 mm | 460 mm | 320 mm | 25 | 7300 mm | 2500 mm | 2350 mm |
| MPBD-3R-3041 | 4100 mm | 30 mm | 25 mm | 510 mm | 460 mm | 30 | 7500 mm | 2800 mm | 2500 mm |
