| Business Type | Manufacturer, Exporter, Supplier |
| Square | 30 X30mm |
| round | 30mm |
| Throat Depth | 240mm |
| Click to view more | |
Preferred Buyer From
| Location | Worldwide |
Product Details
Maximum capacity
26 X 26mm
Type
Ironworker Machine
Automatic Grade
Automatic
Condition
New
Diameter x Thickness
32x12mm
Stroke
70mm
No.of Strokes (per/min)
9~27
Angle Sectoin(90 Degree)
120 x 120 x 12mm
Angle Section(45 Degree)
80 x 80 x 8mm
Length x Thicknes
230 x 20mm
Max. Length x Thickness
375x10mm
Blade Length
400mm
Shearing With Angle
100 x 15mm
Thickness
10mm
Width
45mm
Length
90mm
Length x Thickness
500 x 5mm
(Lx W x H)
1700 x 900 x 1670
Technical data
| TONNAGE | EMT-65 Ton | EMT-85 Ton | EMT-115 Ton | EMT-155 Ton |
| Maximum Capacity | 26 X 26mm | 30 x 20mm | 35 x 25mm | 30 x 30mm |
| Diameter x Thickness | 32 X 12mm | 38 x 15mm | 40 x 20mm | 44 x 20mm |
| Stroke | 70mm | 80mm | 80mm | 100mm |
| No.of Strokes (per/min) | Sep-27 | Sep-36 | Jun-30 | Jul-28 |
| Throat Depth | 240mm | 355mm | 400mm | 450mm |
| Round | 30mm | 50mm | 56mm | 80mm |
| Square | 30 x 30mm | 50 * 50mm | 56 * 56mm | 80 * 80mm |
| Angel Section(90 Degree) | 120 x 120 x 12mm | 160 x 160 x 15mm | 180 x 180 x 14mm | 200 x 200 x18mm |
| Angel Section(45 Degree) | 80 x 80 x 8mm | 80 x 80 x 10mm | 80 x 80 x 10mm | 100 x 100 x 10mm |
| Length xThickness | 230 x 20mm | 330 x 20mm | 355 x 25mm | 300 x 30mm |
| Max. Length x Thickness | 375 x 10mm | 480 x 10mm | 600 x 15mm | 750 x8mm |
| Blade Length | 400mm | 482mm | 610mm | 760mm |
| Shearing With Angle | 100 x 15mm | 120 x 15mm | 120 x 15mm | 120 x 15mm |
| Thickness | 10mm | 13mm | 13mm | 16mm |
| Width | 45mm | 50mm | 60mm | 60mm |
| Length | 90mm | 100mm | 100mm | 100mm |
| Length x Thickness | 500 x 5mm | 500 x 3mm | 700 x 3mm | 700 x 4mm |
| Length x Thickness | 120 x 58mm | 160 x 74mm | 200 x 90mm | 240 x 105mm |
| 90 x 11mm | 100 x 11mm | 120 x 13mm | 150 x 15mm | |
| 4kw | 5.5kw | 7.5kw | 11kw | |
| 1600kg | 2400kg | 3100kg | 5800kg | |
| (L x W x H) | 1700 x 900 x 1670 | 1930 x 900 x 1830 | 2240 x 850 x 1960 | 2700 x 1020 x 2116 |
