| Business Type | Manufacturer, Exporter, Supplier |
| Type | Radial Drill Machines |
| Automatic Grade | Automatic |
| Driven Type | Electric |
| Click to view more | |
Preferred Buyer From
| Location | Worldwide |
Product Details
Drilling Capacity in Steel
25 mm
Drilling Capacity in Casting
30 mm
Tapping Capacity in Casting
20 mm
Maximum Distance from Spindle to Column
24
Minimum Distance from Spindle to Column
10
Maximum Distance from Spindle to Base Plate
30
Diameter of Column
5.32
No. of Spindle Speeds
A+4=8
Range of Spindle Speeds
80-700 rpm
Working Surface of Base Plate
9
Travel of Spindle
6
Spindle Morse Taper No.
3
Vertical Adjustment of Arm
15
Over all Height
60
Arm Tilt Any Angle
upto 90
Floor Space Required
36
Eletricals Motor Required
1 H.P.
Technical Specification
| Technical Specification | MODEL NO | |||
| EMT 25MM | EMT 32MM | EMT 40MM | EMT 50MM | |
| DRILLING CAPACITY IN STEEL | 25 MM | 32 MM | 40 MM | 50 MM |
| DRILLING CAPACITY IN CASTING | 30 MM | 35 MM | 45 MM | 55 MM |
| TAPPING CAPACITY IN CASTING | 20 MM | 25 MM | 25 MM | 30 MM |
| MAXIMUM DISTANCE FROM SPINDLE TO COLUMN | 24" | 32" | 36" | 48” |
| MINIMUM DISTANCE FROM SPINDLE TO COLUMN | 10" | 12" | 12" | 18" |
| MAXIMUM DISTANCE FROM SPINDLE TO BASE PLATE | 30" | 34" | 40" | 50" |
| DIAMETER OF COLUMN | 5.1/2” | 7” | 9” | 10” |
| NO. OF SPINDLE SPEEDS | 4+4=8 | 3+3=6 | 3+3=6 | 3+3=6 |
| RANGE OF SPINDLE SPEEDS | 80-700 RPM | 80-700 RPM | 50-760 RPFM | 40-750RPM |
| WORKING SURFACE OF BASE PLATE | 9” | 11” | 12” | 15” |
| TRAVEL OF SPINDLE | 6” | 8” | 9” | 12” |
| SPINDLE MORSE TAPER NO. | 3 | 4 | 4 | 5 |
| VERTICAL ADJUSTMENT OF ARM | 15" | 18" | 2" | 24" |
| OVER ALL HEIGHT | 60" | 70" | 80" | 90" |
| ARM TILT ANY ANGLE UPTO | 90" | 90" | 90" | 90" |
| FLOOR SPACE REQUIRED | 36" * 21" | 44" * 25" | 55" * 30" | 61" * 32" |
| ELETRICALS MOTOR REQUIRED | 1 H.P. | 2 H.P. | 3HP. | 5H.P. |
